Run7
Touch_Panel AT mode VSWR METER Lo Power AT position Tank_length　(m) Shunt inpedance Ez calc (MV/m) Ez design (MV/m) Power design value
Tank No. pulse(26mA) pulse_deg FF(26mA) FF_deg AT1 AT2 VAC1（S*A) VAC2(S*B) S**A(deg) S**B(deg) V1:Pf V2:Pf V3:Pf TK:T1 TK:T2 V1:Pr V2:Pr V3:Pr V1:VSWR V2:VSWR V3:VSWR AT1(bead) AT2(bead) S**A S**B Mohm/m S**A (T1>MV/m) S**B (T2>MV/m) S**A (Design>MV/m) S**B (Design>MV/m) S**A S**B
BUN1 5781 330.1 1300 81.0 none none none 9 9 0 47 0 0.2 0.2 0 1.43 1.44 none 324.73
BUN2 4177 201.2 1100 283.0 none none none 10 9 0 51 0 0.2 0.2 0 1.34 1.38 none 323.16
CHOP 5000 287.5 0 0.0 none none none 34 34 262 315 0.1 1.13 1.00 none 344.13
RFQ 3970 0.0 1100 60.0 none none
D01 3596 274.0 1300 314.0 36.66 54.03 1.15E-05 1090 480 440 840 850 0 20 20 1.00 1.57 1.54 9.92 58.59 2.23 2.50 1059.66
D02 3919 234.0 1166 278.0 36.04 34.04 1.45E-05 1230 480 540 1070 1040 0 0 0 1.00 1.28 1.28 41.00 34.00 9.44 64.29 2.70 2.70 1070.45
D03 3872 329.0 1126 17.0 22.20 31.94 7.35E-06 960 410 410 920 930 0 10 0 1.00 1.39 1.33 34.00 32.00 7.32 64.01 2.84 2.90 962.06
S01 2872 25.9 525 50.0 62.20 59.88 7.27E-06 1.17E-05 -6deg +1deg 410 175 176 120 179 0 17 17 1.00 1.93 1.90 59.00 1.47 1.51 56.32 56.84 2.14 2.60 2.53 2.53 167.17 169.66
S02 2788 78.7 600 105.0 45.67 44.00 2.95E-06 4.16E-06 +3deg -3deg 490 216 209 220 200 0 22 21 1.00 1.96 1.94 44.00 45.00 1.54 1.58 56.71 56.58 2.84 2.68 2.73 2.73 202.76 208.12
S03 3781 115.7 660 140.0 62.36 52.53 3.76E-06 9.00E-07 -1deg -1deg 680 263 273 470 340 0 25 24 1.00 1.91 1.85 63.00 55.00 1.62 1.66 56.43 56.27 4.05 3.40 2.95 2.95 249.49 256.19
S04 3549 292.3 725 330.0 44.94 50.85 2.61E-06 1.76E-06 -4deg +5deg 800 339 324 460 310 0 15 11 1.00 1.56 1.47 52.00 60.00 1.70 1.74 56.09 55.90 3.90 3.16 3.19 3.19 307.69 316.07
S05 3611 259.7 600 290.0 41.40 42.36 2.97E-06 2.89E-06 +7deg 0deg 850 361 377 510 350 0 18 17 1.00 1.58 1.54 46.00 47.00 1.78 1.82 55.69 55.46 4.00 3.27 3.44 3.44 377.61 387.96
S06 3553 252.0 575 277.0 54.46 56.17 2.87E-06 3.95E-06 0deg +2deg 1140 490 530 540 580 0 20 20 1.00 1.63 1.53 60.00 61.00 1.86 1.90 55.23 54.97 4.00 4.09 3.74 3.74 471.24 484.29
S07 3625 215.2 650 247.0 56.65 74.99 1.81E-06 1.39E-06 -3deg +4deg 1120 490 480 530 490 0 20 20 1.00 1.60 1.62 59.00 77.00 1.95 1.99 54.72 54.46 3.86 3.67 3.74 3.74 497.24 509.99
S08 3374 350.0 520 10.0 70.51 64.07 1.17E-06 6.46E-07 +2deg -5deg 1150 480 510 500 550 0 20 20 1.00 1.53 1.60 73.00 67.00 2.03 2.06 54.21 53.95 3.66 3.79 3.74 3.74 522.60 535.06
S09 3452 296.9 530 322.0 60.81 64.16 7.76E-07 7.81E-07 +6deg -5deg 1230 480 500 530 510 0 10 20 1.00 1.51 1.52 63.00 66.00 2.10 2.14 53.69 53.44 3.68 3.57 3.74 3.74 547.37 559.49
S10 3351 182.8 450 220.0 53.20 55.63 1.23E-06 1.28E-06 +5deg 0deg 1150 520 540 580 580 0 10 20 1.00 1.41 1.47 59.00 60.00 2.17 2.21 53.19 52.95 3.77 3.73 3.74 3.74 571.47 583.27
S11 3436 260.9 530 290.0 45.68 47.09 9.10E-07 1.84E-06 0deg +2deg 1160 540 540 630 630 0 10 10 1.00 1.39 1.44 43.00 52.00 2.24 2.27 52.70 52.46 3.85 3.81 3.74 3.74 594.91 606.39
S12 3138 213.0 400 240.0 57.89 51.23 1.64E-06 1.22E-06 -8deg -9deg 1040 570 580 650 540 0 10 10 1.00 1.40 1.41 62.00 54.00 2.31 2.34 52.22 51.99 3.84 3.47 3.74 3.74 617.69 628.84
S13 3443 168.6 450 207.0 39.63 43.74 1.62E-06 1.68E-06 0deg -5deg 1340 590 590 620 640 0 10 10 1.00 1.41 1.40 43.00 47.00 2.37 2.40 51.76 51.53 3.68 3.71 3.74 3.74 639.82 650.63
S14 3302 97.1 380 105.0 49.61 54.98 1.49E-06 9.30E-07 -7deg -13deg 1320 590 610 620 670 0 10 0 1.00 1.41 1.29 53.00 59.00 2.43 2.45 51.31 51.10 3.62 3.74 3.74 3.74 661.29 671.78
S15 3353 192.9 400 215.0 44.19 52.19 2.68E-06 1.43E-06 +5deg +3deg 1280 630 620 680 620 0 10 10 1.00 1.41 1.34 47.00 55.00 2.48 2.51 50.88 50.67 3.73 3.54 3.74 3.74 682.10 692.28
DB1(S16B) 4080 343.5 600 80.0 51.95 none 8.60E-07 none +3deg 160 69 0 80 60 0 21 0 1.00 3.55 none 55.00 59.00 2.53 2.56 50.47 50.27 1.26 1.09 3.74 3.74 702.29 712.16
DB2(S16A) 4500 216.0 1950 349.0 49.24 none 6.54E-07 none +0deg 11 10 0 8 14 3.5 3.6 0 3.55 3.92 none
